TTL-XT Extreme Temperatures Lighting
UL/FCC/IP65/IP66/IP68/LM80
MIL-STD-810G (-80°C) + MIL-STD-810H (+115°C)
Download Product Catalog (UL)
Download Product Catalog (CB_PSE)
Download Product Catalog (CB_CE)
TTL-XT Products
View Other Product Types
TTL-XT 500W
Download Spec Sheet
View Certifications
LM-79, UL1598 (IFAM7), UL1598 (IFAM), MIL-STD-810H
This 500W LED light delivers 62,500 lumens at 5000K with a high efficacy of 125 lm/W and a focused 70° beam angle. Designed with durable housing options and >20kV surge protection, it operates reliably in extreme temperatures from -80°C to 115°C while meeting MIL-STD-810 standards.
Specifications
Light Source
LED – Static
Lumens
60000 LM
CCT / LED Color
4000 K, 5000 K
CRI
70, 80, 90
Environmental Listing
Wet Location
Regulatory Listing
UL1598
Product Type
High-Heat Lighting Solutions
Voltage Rating
100, 120, 200, 208, 240, 250VDC, 277, 347, 480, 600
Primary Material
Aluminum
Housing
C5M, PVDF
Beam Angle
70 °
Power Cord
600V/200ﾟC rated
Surge Protection
>20KV
Ambient Temp.
MIL-STD-810G (–80 °C) + MIL-STD-810H (+115 °C)
TTL-XT 350W
Download Spec Sheet
View Certifications
LM-79 (1), LM-79 (2), UL1598 (IFAM7), UL1598 (IFAM), MIL-STD-810H
This 350W LED light produces 43,750 lumens at 5000K with high efficiency and beam angle options of 70° or 110°. Built with durable housing, >20kV surge protection, and MIL-STD-810 certification, it performs reliably in extreme temperatures from -80°C to 115°C.
Specifications
Light Source
LED – Static
Lumens
42000 LM
CCT / LED Color
4000 K, 5000 K
CRI
70, 80, 90
Environmental Listing
Wet Location
Regulatory Listing
UL1598
Product Type
High-Heat Lighting Solutions
Voltage Rating
100, 120, 200, 208, 240, 250VDC, 277, 347, 480, 600
Primary Material
Aluminum
Housing
C5M, PVDF
Beam Angle
70 °, 110 °
Power Cord
600V/200ﾟC rated
Surge Protection
>20KV
Ambient Temp.
MIL-STD-810G (–80 °C) + MIL-STD-810H (+115 °C)
TTL-XT 225W
Download Spec Sheet
View Certifications
LM-79 (1), LM-79 (2), UL1598 (IFAM7), UL1598 (IFAM), MIL-STD-810H
This 225W LED light delivers powerful illumination at 5000K with beam angle options of 70˚ or 110˚ for versatile applications. Featuring durable housing, >20kV surge protection, and MIL-STD-810 certification, it ensures reliable performance in extreme temperatures from -80˚C to 115˚C.
Specifications
Light Source
LED – Static
Lumens
27000 LM
CCT / LED Color
4000 K, 5000 K
CRI
70, 80, 90
Environmental Listing
Wet Location
Regulatory Listing
UL1598
Product Type
High-Heat Lighting Solutions
Voltage Rating
100, 120, 200, 208, 240, 250VDC, 277, 347, 480, 600
Primary Material
Aluminum
Housing
C5M, PVDF
Beam Angle
70 °, 110 °
Power Cord
600V/200ﾟC rated
Surge Protection
>20KV
Ambient Temp.
MIL-STD-810G (–80 °C) + MIL-STD-810H (+115 °C)
TTL-XT 10W~140W
Download Spec Sheet (10W~140W)
Download Spec Sheet (45W)
View Certifications
CB-100V (1), CB-100V (2), CB-200V (1), CB-200V (2), CE-100V, CE-200V, EMC-100V, EMC-200V, IES Rep.-20W, IES Rep.-35W, IES Rep.-70W, IES Rep.-105W, IES Rep.-140W, Surge, UL1598 (IFAM7), UL1598 (IFAM), MIL-STD-810H
This versatile LED light offers 10W–140W power options with up to 125 lm/W efficacy and a 110˚ wide beam angle at 4000K or 5000K. Built with durable housing, stainless steel components, and >15kV surge protection, it ensures reliable performance in extreme environments from -80˚C to 125˚C, meeting MIL-STD-810 standards.
Specifications
Light Source
LED – Static
Lumens
1200~16800 LM
CCT / LED Color
4000 K, 5000 K
CRI
70, 80, 90
Environmental Listing
Wet Location
Regulatory Listing
UL1598
Product Type
Round(45W) / Linear (10~140W, excl. 45W)
Voltage Rating
100, 120, 200, 208, 240, 250VDC, 277, 347, 480, 600
Primary Material
Aluminum
Housing
C5M, PVDF
Beam Angle
70˚ (45W) / 110˚ (10~140W, excl. 45W)
Power Cord
600V/200ﾟC rated
Surge Protection
>15KV
Ambient Temp.
MIL-STD-810G (–80 °C) + MIL-STD-810H (+115 °C)
